Revel Concerta M10 - On-Wall Speaker
M10
As the left and right speakers in a music system, or perfectly matched to the Concerta C10 in a home theater system, the M10 delivers superb music reproduction and realistic, all encompassing movie sound to rooms of virtually any size.
M10 Highlights
- Rigid aluminum enclosure
- Micro Ceramic Composite (MCC) Cone Woofers
- 1'' Tweeter
- Wall brackets
- Three different bases included
- Option STANDM10 loudspeaker stand
|
Height |
22.9" (58.2 cm) |
|
Width |
4.3" (10.8 cm) |
|
Depth |
4.5" (11.4 cm) |
|
Weight |
3.1Kg |
|
Crossover Frequencies |
2-1/2-Way at 400Hz and 2.2kHz |
|
Input Sensitivity |
400mV (full power)/20k Ohms (balanced); 14k Ohms (unbalanced) |
|
Inputs |
Balanced (XLR), unbalanced (RCA) |
|
High Frequency Driver Components |
1" (2.5 cm) micro-ceramic composite (MCC) cone tweeter |
|
Low Frequency Extension |
–3dB @ 110Hz –6dB @ 100Hz –10dB @ 90Hz4Hz |
|
Mid-frequency Driver Components |
Dual 3" (7.5 cm) micro-ceramic composite (MCC) cone woofers |
|
Low-frequency Driver Components |
Dual 3" (7.5 cm) micro-ceramic composite (MCC) cone woofers |
|
Sensitivity |
89 db |
|
Nominal Impedance |
8 Ohms |
|
