Arcam A5+ Integrated Amplifier
Inclusive of all taxes
GET GST INPUT
Ever wondered why speakers, amplifiers, projectors etc. come with a slightly heftier price tag in India compared to their overseas counterparts? Well, part of the answer lies in our country's Goods & Services Tax (GST).
But here's the kicker: Don't let that GST input slip through your fingers! Especially when some of the products we supply carry a GST rate of 18% and 28%.
At AVStore, we provide you with a GST compliant invoice for every purchase.
Simply put in your GST number during the checkout to avail an offset.
- Description
- Specifications
- Reviews
The "A" in ARCAM stands for amplification, the area where ARCAM's expertise was built. The A5+ is the latest evolution of nearly 50 years of amplifier design and manufacturing, tracing its heritage back to the first product in 1976 — the A&R Cambridge A60 amplifier. Building on the success of the award-winning ARCAM Radia A5, the A5+ has been developed to deliver even better sound quality and greater versatility.
The A5+ features an enhanced power supply design and cutting-edge wireless capabilities straight out of the box. Snapdragon Sound delivers uncompressed digital audio via Bluetooth, while Auracast enables multiple compatible headphones or speakers to share music wirelessly, with no pairing required.
With a wide array of digital and analogue inputs, including a meticulously tuned phono stage, the A5+ ensures exceptional sound quality for everything from vinyl playback to music streaming.
Key Features
- ARCAM Class AB Amplification – Delivers exceptional musicality and performance.
- 2 x 50W Power Output – Drives loudspeakers with ease and control.
- Snapdragon Sound & Auracast Built-In – Advanced wireless audio with outstanding convenience.
- Wired or Wireless Headphone Support – Enjoy private listening with or without cables.
- Fine-Tuned Phono Stage – Brings out the detail, warmth, and engagement in vinyl records.
-
Plastic-Free Packaging – Designed for easy disposal and reduced environmental impact.
SPECIFICATION
|
8Ω, 20Hz ‑ 20kHz |
50W |
|
4Ω, 1kHz, |
75W |
|
Harmonic distortion, 80% power, 8Ω at 1kHz |
0.003% |
|
Number of inputs |
3 (RCA pairs) |
|
Signal/noise ratio (A-wtd, ref. 50W, 1V input) |
106dB |
|
Frequency response |
20Hz-20kHz ± 0.2dB |
|
Input impedance |
47ΚΩ + 100pF |
|
Frequency response (ref. RIAA curve) |
20Hz-20kHz ± 1dB |
|
Supported Sample Rates (kHz) |
192, 176.4, 96, 88.2, 48, 44.1 |
|
Bit depths (bit) |
24, 16 |
|
Frequency response (filter 1) |
20Hz-20kHz ± 0.2dB |
|
Signal/noise ratio (A-wtd, ref. 50W, 0dBFS) |
109dB |
|
Maximum output level (RMS) into 32Ω/300Ω |
2.5V/5V |
|
Load range |
16Ω - 2kΩ |
|
Bluetooth Version |
5.4; A2DP Sink/Source, AVRCP, BLE, Snapdragon Sound, AAC, LE Audio, Auracast |
|
Bluetooth Transmitter Frequency and Power |
2,400 MHz to 2,483.5 MHz: <20dBm |
|
Mains voltage |
100V or 110-120V or 220-240V, 50-60Hz |
|
Power consumption (maximum) |
350W |
|
Power consumption (standby) |
<0.5W |
|
Dimensions WD (including speaker terminals) x H (including feet) |
431 * 344 * 83mm |
|
Weight (net) |
8.14 kg |
|
Weight (packed) |
11.36kg |
