Accuphase Laboratory E-3000 Integrated Stereo Amplifier
Inclusive of all taxes
GET GST INPUT
Ever wondered why speakers, amplifiers, projectors etc. come with a slightly heftier price tag in India compared to their overseas counterparts? Well, part of the answer lies in our country's Goods & Services Tax (GST).
But here's the kicker: Don't let that GST input slip through your fingers! Especially when some of the products we supply carry a GST rate of 18% and 28%.
At AVStore, we provide you with a GST compliant invoice for every purchase.
Simply put in your GST number during the checkout to avail an offset.
- Description
- Specifications
- Reviews
The E-3000 integrated amplifier emerged from the path forged by the technologies used in high-end equipment. Among this amplifier’s constituent elements, the vitally important volume control circuits incorporate AAVA that employs the ANCC principle. The power amplifier section produces balanced signals relying on the instrumentation amplifier principle while simultaneously creating a robust output stage through three-fold parallel push-pull power transistors driven in class AB. Every moment spent immersed in the vibrant playback of the E-3000 is one to relish.
Key Features
- AAVA volume control circuit
- Powerful 100 watts into 8 ohms, 150 watts into 4 ohms
- Three-fold parallel push-pull configuration using power transistors driven in Class AB
- Power amplification stage configured as an instrumentation amplifier
- High damping factor of 600
- Balanced remote sensing to improve the damping factor
- Current feedback amplification circuit topology assures excellent phase characteristics in the high range
- Strong power supply with massive transformer and high-voltage, large filtering capacitors
- Protection circuitry using MOS-FET switches
- Tone controls using summing active filters
- High-carbon cast iron insulators for superior vibration damping
- Two expansion slots for option board
|
Product Type |
Integrated Stereo Amplifier |
|
Amplifier Class |
Class AB |
|
Output Power (8Ω) |
100W + 100W |
|
Output Power (4Ω) |
150W + 150W |
|
Damping Factor |
600 |
|
Frequency Response |
20Hz – 20kHz |
|
Total Harmonic Distortion (THD) |
0.05% |
|
Signal-to-Noise Ratio |
107dB (Line) |
|
Input Sensitivity |
142mV (Line) |
|
Speaker Impedance |
4Ω – 16Ω |
|
Volume Control |
AAVA (Accuphase Analog Vari-gain Amplifier) |
|
Amplifier Topology |
Instrumentation Amplifier |
|
Output Stage |
Three-Fold Parallel Push-Pull |
|
Protection Circuit |
MOS-FET Switch Protection |
|
Feedback Circuit |
Current Feedback Amplification |
|
Remote Sensing |
Balanced Remote Sensing |
|
Tone Controls |
Summing Active Filters |
|
Expansion Slots |
2 (DAC-60 / AD-60 Compatible) |
|
Analog Inputs (RCA) |
5 |
|
Balanced Inputs (XLR) |
1 |
|
Pre-Out |
Yes |
|
Main-In |
Yes |
|
Headphone Output |
Yes |
|
Power Supply |
Large EI Transformer with High-Capacity Filter Capacitors |
|
Filter Capacitors |
2 × 33,000µF |
|
Insulators |
High-Carbon Cast Iron |
|
Width |
465 mm |
|
Height |
161 mm |
|
Depth |
422 mm |
|
Weight |
23.1 kg |
