Parasound 12-Zone Audio Power-Compact, Precise, and Ready
The ZM12 packs twelve channels of powerful amplification into a compact 2U rack unit-perfect for delivering music or voice across multiple rooms without taking up space. It combines robust power with flexibility, making it ideal for home or commercial multi-room sound systems.
The ZM12 powers 12 channels across 6 zones, with Zone 1 at 120 W/ch into 8 Ω (150 W into 4/2 Ω) and Zones 2-6 at 60/100 W. A Class‑AB input stage feeds premium Class‑D modules that are stable at 2 Ω, while A/B speaker outputs per channel (24 total) and stereo/mono per‑zone switching simplify real‑world wiring. Integration is painless with per‑zone audio‑sensing and 12 V triggers plus a speaker‑level input for systems without pre‑outs.
Features
- Parasound’s new ZoneMaster® models are very similar in their feature sets, differing mainly in size and number of channels. Looking for fewer channels? Try ZoneMaster® ZM2 or ZM4.
- Universal amplifier for applications from 60 to 150 watts
- Zone 1 (channel 1&2) are higher power for more demanding applications
- 24 speaker connections (A and B outputs for all 12 channels)
- High current for stable operation at 2 Ohms
- Class AB input stage plus premium Class D power stage
- Independent audio sensing triggers, one for each zone
- 6 Independent 12 volt trigger inputs, one for each zone
- Looping 12 volt trigger outputs for each zone
- Master 12 volt trigger input to turn all zones on-off
- Speaker level input for expanding systems w/out pre out jacks
- Two bus inputs can be routed to any zone
- Bus loop output jacks for passing audio to another amp
- Summed Mono mode combines L and R for single speaker applications
- Separate level controls for all twelve channels
- Detachable speaker connectors accept up to 12 gauge wire
- Short circuit and overheat protection with front panel indicators
- 0.5 watt standby power consumption meets Energy Star & EU specs
- Compact 2U chassis
- 2U rack mounting hardware is included in box<
AVStore India is proud to be an authorized dealer of Parasound, offering genuine products, official manufacturer warranty, and expert assistance before and after your purchase.
|
Power Output: |
Zone 1 (Channel 1-2) 150 watts x 2 @ 42 or 2Ω |
|
Power Output |
Zone 2-6 (Channels 3-12) 100 watts x 10 @ 42 or 2Ω |
|
Minimum Speaker Impedance: |
A+B Outputs of a Single Channel: 2 Ω Note: Continuous operation at this minimum impedance might require additional ventilation for the amplifier. |
|
Frequency Response: |
20 Hz-20 kHz, +0/-0.25 dB 5 Hz-50 kHz, +0/-3 dB |
|
Total Harmonic Distortion: |
< 0.05% at typical listening levels < 1.0% at full power |
|
Interchannel Crosstalk: |
70 dB at 20 kHz |
|
Total Gain: |
29 dB (Level controls set to Maximum) |
|
S/N Ratio: |
>112 dB, input shorted, IHF A-weighted |
|
DC Trigger Requirements: |
+9 Vdc to +12 Vdc, 5 mA |
|
Audio Trigger Requirements: |
2 mV audio signal |
|
AC Power Requirement: |
1550 Watts maximum 150 Watts typical (audio playing on all zones) 55 Watts idle (all zones on) 15 Watts idle (one zone on) 0.5 Watts standby 100-250 VAC 50/60 Hz (automatic) |
|
Dimensions: |
Width: 17.25" (437 mm) Depth: 14.5" (369 mm) Depth, with cables: 16" (406 mm) Height, with feet: 4.15" (105 mm) Height, without feet: 3.5" (89 mm) |
|
Weight: |
Net: 21 lbs (9.5kg) Shipping: 27 lbs (12.2kg) |
