JVC DLA-X5900BE 4K E-SHIFT5 3D PROJECTOR

JVC DLA-X5900BE D-ILA projector lets viewers see the details even in the brightest highlights and darkest shadows with the new 4K e-shift5 technology that employs completely new algorithms to realize even higher definition and improved 4K picture quality. The projector is designed deliver dynamic HDR images with a several manual controls including HDR Auto Picture mode, Picture Tone, and Bright/Dark level gamma adjustment. Complies with the HDMI/HDCP 2.2 standard, and best of all the projector also features user-friendly technologies to create images that match the viewing environment and enhance viewing experience.

• D-ILA high contrast ratio delivers images full of presence

  JVC’s original D-ILA device combined with and an optical engine equipped with a wire grid that complements the new high-output lamp results in high native contrast ratio of 160,000:1*. Input signals are analysed with an original algorithm that is combined with Intelligent Lens Aperture, which automatically controls the black level of the image to achieve an ultimate dynamic contrast of 1,600,000:1*. The synergetic effect based on the ultimate dynamic range stemming from high-brightness, delivers sensational 4K video full of reality.
  * DLA-X9900BE



  New 4K e-shift5 technology for improved definition



  JVC’s e-shift technology, which shifts sub-frames by 0.5 pixels vertically and horizontally to achieve 4 times the pixel density of the original content, has evolved to meet the growing demand for 4K. Now e-shift5 technology employs completely new algorithms to realize a dramatic boost in diagonal detection precision, thus achieving even higher definition and improved picture quality.

  Auto-Calibration Function

  Using an optical sensor, precise calibration can be performed in just a few easy steps to match the changes in optical characteristics caused by the installation situation of the projector. Auto-Calibration optimises all essential elements found in the image, including colour balance, gamma characteristics, colour space, and colour tracking.
  *JVC software and optical sensor are required to set viewing configurations and auto calibration. Please visit the JVC website for the details.



  High-quality video with Low Latency Mode

  D-ILA projectors feature an improved Low Latency Mode* that ensures faster response with PC and game console content. In addition, when this mode is active high-bandwidth signals such as 4K with 10-bit or 12-bit colour depth can be processed without compression, resulting in high-quality video performance without any deterioration, regardless of source.
  * The feature cannot be used with 3D playback mode or 3D Clear Motion Drive.



  Lens Memory Function

  This function stores ten* separate lens adjustments for zoom, shift and focus that can be easily recalled when needed. Memory settings can be switched between each setup via the remote controller.
  *: DLA-X9900BE and DLA-X7900BE/WE have ten, DLA-X5900BE/WE has five.



  Screen Adjustment Modes

  The projector selects the best mode to match the screen being used, for images with natural colour balance. The modes are compatible with the latest models offered by the world’s major screen manufacturers.*
  * Please refer to JVC website for a comparison table of primary screens and adjustment modes



  Features

  • Connectors: HDMI x 2 (3D, Deep Colour/HDCP 2.2), RS-232C (D-sub 9pin) x 1, LAN (RJ-45) x 1, Trigger x 1 (Mini jack), 3D Sync x 1 (Mini DIN)
  • Exceptionally bright 1,800 lm achieved with 265W high-output NSH lamp
  • 4K Projection (3840 x 2160 pixels*) achieved with optical engine featuring e-shift 5 Technology with Multiple Pixel Control image processor
  • 6th generation 0.7" Full HD D-ILA (1920 x 1080) device x 3
  • 4K signal input (4K60P 4:4:4, 4K60P 4:2:2/36-bit, 4K24P 4:4:4/36-bit)
  • NSH 265W
  • Ultimate dynamic contrast ratio of 400,000:1 and native contrast ratio of 40,000:1 achieved with original D-ILA device and the high-output lamp
  • For easy reproduction, the projector switches automatically to HDR picture mode when HDR10 signals are received
  • Display the MaxCLL and MaxFALL mastering data available for HDR content on some UHD Blu-ray discs
  • Compatible with Hybrid Log-Gamma that will come into use for broadcasting applications

  • Colour Management System with 6-axis Matrix
  • Auto-Calibration Function using an optical sensor** is capable of optimizing essential elements in the image, including colour balance, gamma characteristics, colour space and colour tracking
  • 12-point manual gamma adjustment included in Auto-Calibration Software
  • Motion Enhance technology reduces residual images and blurring that are often found in fast-moving images by optimally controlling the drive of D-ILA devices
  • Low Latency Mode suppresses display delay for faster response when receiving signals from PC and game consoles
  • When Low Latency Mode is active, high-bandwidth signals like 4K with 10-bit or 12-bit colour depth can be processed without compression
  • Pixel Adjust function allows user to precisely correct colour deviation in 1/16-pixel increments; also segments the screen into 121 points for individual adjustment. Two customized settings can be stored in the memory.
  • *Resolution is 1920 x 1080 at 3D mode **Exclusive JVC software installed in PC and optical sensor are required. Please visit the JVC website for details.
  • 4K resolution (3840 x 2160) achieved with e-shift 5 Technology including Multiple Pixel Control image processor*
  • Resolution: 3840 x 2160 (in 2D)*; 1920 x 1080 (in 3D)
  • Screen Adjustment Modes: 143 modes
  • Lens Memory function (5 memories)
  • Wireless transmission options for 3D viewing: RF (radio frequency) system transmission with PK-AG3 3D Glasses for 100H continuous operation and PK-EM2 3D Synchro Emitter
  • Complies with the latest HDMI/HDCP 2.2 standard to enable full spec 4K signal input up to 4K60P 4:4:4
  • To match the trends towards higher resolution and to deliver immersive high-definition 4K images, Multiple Pixel Control has been improved with a new analysis algorithm capable of more accurate diagonal-detection between frames for full HD and 4K resolution signals.
  • Clear Motion Drive compatible with signals up to 4K60P 4:4:4, can reproduce moving images without ghosting or afterimage issues
