JBL STAGE A135C
Enjoy enhanced dialogue from your favourite movies and TV shows with your amplifier and the black JBL Stage Series A135C Two-Way Center-Channel Speaker. It features a 1" aluminium-dome tweeter and six 3" polycellulose woofers, and accepts 20 to 150W of power from your amplifier. The side-firing, bass-reflex ports help enhance the low frequency response. As a centre channel, when integrated with the rest of your home theatre system, it will produce primarily on-screen dialogue rather than the sound effects coming from the rest of your speakers. Measuring just over 4” tall, the A135C is the perfect low-profile centre channel to anchor your JBL Stage surround sound system.
SPECIFICATIONS
Design |
2-way |
Tweeter |
1x 1" / 25 mm aluminum dome |
Woofers |
6x 3" / 76 mm polycellulose woofers |
Recommended Amplifier Power |
20 to 150 W |
Frequency Response |
75 Hz to 40 kHz |
Sensitivity dB @ 2.83 V/1 m |
90 dB |
Nominal Impedance |
6 Ohms |
Crossover Frequency |
2.5 kHz |
Enclosure Type |
Bass-reflex via side-firing ports |
Dimensions (W x H x D) |
29.33 x 4.09 x 6.54" / 745 x 104 x 166 mm |
Weight |
16.42 lb / 7.45 kg |
